Name: Accucold 24" Wide Refrigerator-Freezer, ADA Compliant Stainless Steel
SKU: 66918

SPECIFICATIONS

Overview
Height of Cabinet	32.0" (81 cm)
Height to Hinge Cap	32.25" (82 cm)
Width	23.63" (60 cm)
Depth	23.5" (60 cm)
Depth with Handle	24.25" (62 cm)
Depth with door at 90°	45.0" (114 cm)
Capacity	5.1 cu.ft. (144 L)
Defrost Type	Cycle
Door	Stainless Steel
Cabinet	Black
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Amps	1.4
Voltage/Frequency	115 V AC/60 Hz
Weight	100.0 lbs. (45 kg)
Shipping Weight	105.0 lbs. (48 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
Refrigerator-Freezer
Door Swing	RHD
Reversible	Factory Reversible
Adjustable Shelves	Yes
Crisper Qty	1
Crisper Finish	Transparent
Crisper Cover	Glass
Interior Light	Yes
Refrigerator - Interior Height	19.5" (50 cm)
Refrigerator - Interior Width	20.5" (52 cm)
Refrigerator - Interior Depth	17.0" (43 cm)
Refrigerator - Shelf Type	Glass
Refrigerator - Shelf Qty	3
Refrigerator - Full Door Shelves	3
Freezer - Interior Height	5.0" (13 cm)
Freezer - Interior Width	19.0" (48 cm)
Freezer - Interior Depth	11.5" (29 cm)
Thermostat Type	Dial
Refrigerant Type	R600a
Refrigerant Amount	0.92 oz.
High Side PSI	180.0
Low Side PSI	80.0
Level Legs	4
Compressor Step Height	7.0" (18 cm)
Compressor Step Width	20.5" (52 cm)
Compressor Step Depth	5.0" (13 cm)

AVAILABLE UPGRADES

Door

STO-Step-To-Open Door Pedal

Step-to-open door pedal allows hands-free access to open the door 90 degrees

Handle

TBC Copper Towel Bar Handle Upgrade

Change this handle to a 12" vertically mounted towel bar style handle made from pure copper for antimicrobial protection

Exterior

DL2B - Factory installed NIST calibrated digital data logger (DDL) USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout	TT - Installed thermometer ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order
PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices	Alarm Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
SS Hinges Stainless steel top and bottom hinges	SCD - Self-closing door Protect interior contents and reduce energy waste with the Self Closing Door Option
ODA - Open door alarm Add an open door alarm to audibly buzz when the door is left ajar.	LHD - Left hand door swing Door reversal to left hand swing
Latch for door Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.	SSK Stainless steel kickplate factory installed
HG - Hospital grade cord Add a hospital grade cord equipped with green dot plug with the HG suffix	DL1 - Factory installed data logger USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac
Agion Door Treat the door with Agion silver antimicrobial coating to reduce the growth of bacteria, fungi, molds, and other destructive microbes on appliance surface

Lock

L-Installed Lock Add a single key lock to the door with the L option	KEYPAD Battery-powered keypad door lock installed for keyless security
AC Keypad Keypad door lock powered by appliance power cord for keyless security

Interior

FCGP internal fan with gel packs

Internal fan with gel packs included for a stabilized interior

FC - Internal Fan

Internal fan for even temperature distribution throughout the unit interior

This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or

California residents:

WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to .
Note: Nickel is a component of stainless steel.

FEATURES

ADA compliant
32 inch height fits under standard ADA counters

Slim undercounter dimensions
Less than 24 inches wide to fit tight spaces

Built-in capable
Make the best use of space by installing your appliance under the counter and flush with other cabinets

Fully finished black cabinet
Allows the unit to be used freestanding

Stainless steel door
Durable design with lasting elegance

Professional towel bar handle
Curved handle in brushed stainless steel offers a sturdy grip with professional elegance

Cycle defrost
This system utilizes user-friendly automatic defrost operation in the fresh food section and efficient manual defrost operation in the freezer compartment

Dual evaporator
Our unique and efficient design separately cools the refrigerator while maintaining a lower temperature in the freezer compartment by utilizing two evaporators

Adjustable glass shelves
Rearrange the refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up

Clear crisper
Get the longest life and best taste out of produce by storing greens in a convenient slide drawer

Door shelves
Store tall bottles and condiments right on the door for convenient access

Interior light
Automatically illuminates when you open the door

Adjustable thermostat
Dial thermostat located inside for easy temperature management

100% CFC free
Environmentally friendly design without ozone-damaging chemicals

DESCRIPTION

Accucold by Summit Appliance offers a wide range of
undercounter refrigeration for general purpose storage.
The AL650BI Series includes refrigerator-freezers designed for
optimum storage conditions in built-in applications under lower
ADA compliant counters.At 32" high, the AL652BKBISSTB can be used built-in or
freestanding in ADA compliant settings. The 24" footprint fits
many popular cutouts while offering over 5 cu.ft. of storage
capacity. This model has a black cabinet and stainless steel
wrapped door. A curved towel bar handle completes the
professional look.Inside, our unique dual evaporator system separately cools the
refrigerator and freezer sections to ensure proper storage
temperature. Cycle defrost operation reduces user maintenance
in the automatic defrost fresh food section, with static manual
defrost operation in the freezer compartment. Door storage
provides easy access for tall bottles and small condiments.
Additional features include adjustable glass shelves, a clear
crisper, and automatic interior lighting.The AL652BKBISSTB has long proven itself to have one of the
best temperature performance records in the industry. To see
additional finish options on this unit, browse the full AL650BI
Series.NOTE: This unit is designed for general purpose, medical, or
commercial applications and does not meet DOE energy standards
for residential use.
